Residential Batteries

T-BAT-SYS-LV-R36

  • 3.6 kWh-58.8 kWh

T-BAT-SYS-LV R36 của SolaX sử dụng công nghệ pin LFP với dung lượng linh hoạt từ 3.6kWh đến 58.8kWh. Pin này kết hợp hoàn hảo với biến tần X1 HYBRID LV, tạo nên một giải pháp năng lượng linh hoạt cho nhu cầu dân dụng, dễ dàng lắp đặt và bảo trì.

Product Advantage

SolaX T-BAT-SYS-LV R36 có hiệu suất cao với hơn 6000 chu kỳ, khả năng truyền năng lượng hiệu quả và tối ưu công suất. Hệ thống quản lý thông minh hỗ trợ chẩn đoán từ xa, giúp bảo trì dễ dàng.  Khả năng thích ứng linh hoạt cho phép lắp đặt nhanh trên tường hoặc trong tủ, đồng thời dễ dàng mở rộng để đáp ứng nhu cầu ngày càng tăng.

Contact Us

Assured Reliability

  • LiFePO4 battery cell & high-performance processors

  • No toxic heavy metals or caustic materials

  • Soft start to protect BAT and INV from a sudden surge


High Performance

  • Long cycle life > 6000 times

  • High capacity utilization

  • Efficient energy transfer


Smart Management

  • Remote fault diagnosis, upgrade and maintenance


Flexible Adaptability


  • Wall quick bracket, or cabinet mounting optional

  • Easy to scale up


Product Parameters

  • T-BAT LR3.6
  • T-BAT LR7.2
  • T-BAT LR10.8
  • T-BAT LR14.4
  • T-BAT LR18.0
  • T-BAT LR21.6
  • T-BAT LR25.2
  • T-BAT LR28.8
  • T-BAT LR32.4
  • T-BAT LR36.0
  • T-BAT LR39.6
  • T-BAT LR43.2
  • T-BAT LR46.8
  • T-BAT LR50.4
  • T-BAT LR54.0
  • T-BAT LR57.6
  • T-BAT LR3.6
    • SYSTEM DATA
      Number of modules1 Module
      Nominal capacity3.6 kWh
      Max.output current50 A
      Peak discharge current

      60 A (60 s)

      100 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR7.2
    • SYSTEM DATA
      Number of modules2 Module
      Nominal capacity7.3 kWh
      Max.output current85 A
      Peak discharge current

      120 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR10.8
    • SYSTEM DATA
      Number of modules3 Modules
      Nominal capacity11.0 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR14.4
    • SYSTEM DATA
      Number of modules4 Modules
      Nominal capacity14.7 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR18.0
    • SYSTEM DATA
      Number of modules5 Modules
      Nominal capacity18.4 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR21.6
    • SYSTEM DATA
      Number of modules6 Modules
      Nominal capacity22.0 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR25.2
    • SYSTEM DATA
      Number of modules7 Modules
      Nominal capacity25.7 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR28.8
    • SYSTEM DATA
      Number of modules8 Module
      Nominal capacity29.4 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR32.4
    • SYSTEM DATA
      Number of modules9 Modules
      Nominal capacity33.1 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR36.0
    • SYSTEM DATA
      Number of modules10 Modules
      Nominal capacity36.8 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR39.6
    • SYSTEM DATA
      Number of modules11Modules
      Nominal capacity40.4 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR43.2
    • SYSTEM DATA
      Number of modules12 Modules
      Nominal capacity44.1 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR46.8
    • SYSTEM DATA
      Number of modules13 Modules
      Nominal capacity47.8 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR50.4
    • SYSTEM DATA
      Number of modules14 Modules
      Nominal capacity51.5 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR54.0
    • SYSTEM DATA
      Number of modules15 Modules
      Nominal capacity55.2 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20



  • T-BAT LR57.6
    • SYSTEM DATA
      Number of modules16 Modules
      Nominal capacity58.8 kWh
      Max.output current120 A
      Peak discharge current

      150 A (60 s)

      200 A (15 s)


    • GENERAL
      Nominal voltage51.2 V
      T-BAT LR3.6 Dimensions (L × W × H)442 × 420 × 130 mm
      T-BAT L3.6 Weigh33 kg
      Battery typeLithium iron phosphate
      IP rating of enclosureIP20
